Cable Type
Screened 3 core cable
Conductor
HOT
D.U.C.C. Stress-free 7N Cu MEXCEL / 0.32φ x 50
COLD
D.U.C.C. Stressfree 7N Cu MEXCEL / 0.32φ x 50
GROUND
Super-anneal 4.5N Cu / 0.32φ x 50
Conductor jacket
Polymer polyolefin
Insulation
Polymeric polyolefin-hybrid (polyolefin + tungsten, amorphous and carbon powder)
Shield
Polyurethane enameled 4N Cu braid with Special shielding technology
Outer Jacket
UV resistant polyurethane
External Diameter
16 mm
Resistance
2.0 m Ohms / m
Capacitance
10 pF / m
Maximum ampacity
50 Ampere
Connector Types
IEC / Wall plug US
Connector
Esoteric ultimate power plug / IEC connector with beryllium copper contact elements (silver + rhodium plating)
Standard Sales Units / Lengths
1.5m* x 1
* Custom lengths of this power cord, made to order,can be manufactured at extra cos
