Overview

A new undertaking to commemorate the 35th Anniversary of the Esoteric legacy; it’s the first-ever turntable in our history, the Grandioso T1. Accommodating a patent-registered unique contact-free drive mechanism, the “Esoteric MagneDrive System”, that inductively synchronizes the rotations of a magnetic driver and platter, realizing a quiet and silky-smooth rotation at an extraordinarily accurate rotation speed.

Features

  • Esoteric’s patented contact-free drive system “Esoteric MagneDrive System”

  • Magne-Float platter greatly reduces spindle bearing friction by reducing platter’s effective mass from 19kg down to approx. 4kg.

  • Consists of 3 separated units: main unit, motor unit, and power supply unit.

  • High quality VCXO motor driver ensures precise platter rotation.

  • 10MHz Clock Sync capability with the Grandioso G1X Master Clock.

  • Inverted bearing system supports smooth rotation of the platter.

  • The Micrometer knob on the front panel provides fine-tuning capability of sonic characteristics, by adjusting the strength of magnetic force being applied from the magnetic driver to the platter.

  • Triple layer chassis made of Aluminum and wood, effectively controls vibration.

  • The mid-chassis is applied with beautiful high gross piano lacquer.

  • The isolation feet have a special damping mechanism that eliminates external vibration.

  • Two speed control (33/45 rpm), adjustable with 0.1% order.

  • The T1 is offered with TA-9D dynamic balance tonearm, or without tonearm configuration.

  • Optional arm-board allows the T1 accommodates up to 3 tonearms.

Get notified by email when this product is in stock.

Overview

A new undertaking to commemorate the 35th Anniversary of the Esoteric legacy; it’s the first-ever turntable in our history, the Grandioso T1. Accommodating a patent-registered unique contact-free drive mechanism, the “Esoteric MagneDrive System”, that inductively synchronizes the rotations of a magnetic driver and platter, realizing a quiet and silky-smooth rotation at an extraordinarily accurate rotation speed.

Features

  • Esoteric’s patented contact-free drive system “Esoteric MagneDrive System”

  • Magne-Float platter greatly reduces spindle bearing friction by reducing platter’s effective mass from 19kg down to approx. 4kg.

  • Consists of 3 separated units: main unit, motor unit, and power supply unit.

  • High quality VCXO motor driver ensures precise platter rotation.

  • 10MHz Clock Sync capability with the Grandioso G1X Master Clock.

  • Inverted bearing system supports smooth rotation of the platter.

  • The Micrometer knob on the front panel provides fine-tuning capability of sonic characteristics, by adjusting the strength of magnetic force being applied from the magnetic driver to the platter.

  • Triple layer chassis made of Aluminum and wood, effectively controls vibration.

  • The mid-chassis is applied with beautiful high gross piano lacquer.

  • The isolation feet have a special damping mechanism that eliminates external vibration.

  • Two speed control (33/45 rpm), adjustable with 0.1% order.

  • The T1 is offered with TA-9D dynamic balance tonearm, or without tonearm configuration.

  • Optional arm-board allows the T1 accommodates up to 3 tonearms.



  • Turntable section

    Rotation speed

    33 ⅓ rpm、45 rpm

    Rotation speed adjustment range

    ±12% (0.1% step)

    Wow and flutters

    0.06% or less (W.R.M.S)

    Clock input

    Connector

    BNC × 1

    Input impedance

    50Ω

    Input frequency

    10MHz (±10ppm)

    Input level

    0.5 to 1.0Vrms (sine wave)

    Tone arm section (TA-9D)

    Type

    Dynamic balance

    Overall length

    326mm

    Effective length

    245mm

    Distance between tone arm axis to spindle

    230mm

    Overhang

    15 ±2mm

    Tracking error

    +2° to 1° 21′

    Needle pressure range

    0 to 5g (0.25g step)

    VTA elevation range

    0 to 10mm

    Cartridge/shell balance range

    6 to 38.5g

    Headshell weight

    16.45g

    General

    Power

    Weight

    AC 120V, 60Hz

    Weight

    AC 220 - 240V, 50Hz

    Power consumption

    8W (standby 0.4W)

    Base unit

    Overall dimensions (W×H×D)

    497 × 215 × 436mm / 19.6” × 8.5” × 17.2” (including protrusions)

    Weight

    17kg / 37.5 lb.

    Platter

    Overall dimensions (Diameter × Height)

    ø315.4 × 103mm / ø12.4” × 4.1”

    Weight

    19kg / 41.9 lb.

    Motor unit

    Overall dimensions (W×H×D)

    180 × 137 × 450mm / 7.1” × 5.4” × 17.7” (including protrusions)

    Weight

    9kg / 19.9 lb.

    Power supply unit

    Overall dimensions (W×H×D)

    445 × 131 × 447mm / 17.5” × 5.2” × 17.6” (including protrusions)

    Weight

    18kg / 39.7 lb.

    Included accessories

    Installing tools
    Spacer block × 1
    Height check guage × 1
    Install guide rail (L) × 1
    Install guide rail (R) × 1
    Main unit protection cover × 1
    Turntable sheet × 1
    DC power cord× 1
    Power cord × 1
    Felt mats (for power supply unit)
    Handles × 2
    Owner’s manual × 1
    Tone arm TA-9D × 1 (not available on the tone arm less model)
    Owner’s manual for TA-9D × 1(not available on the tone arm less model)
    Arm base × 1(not available on the tone arm less model)

    * Design and specifications are subject to change without notice.
